BigTreeTech Chaotic Lab CNC Voron Tap V2

Free shipping in Canada for orders over $140 before tax. (via Canada Post)

Thanks to Voron Design and Badnoob
We sincerely thank the Voron Design team for their open source project that enabled us to develop the CNC Voron Tap.We especially want to recognize Badnoob, creator of Voron Tap, for participating in the iterative R&D of the CNC Voron Tapand providing valuable feedback on our V2 version. Badnoob also aided in internalproduct testing to help us evaluate the performance and reliability of the CNC Voron Tap V2.

The openness and creative spirit exhibited by Voron Design and Badnoob have made tremendous contributions to the 3D community. Chaoticlab will continue embracing these open source values to jointly advance 3D printing.

 Why MGNH7?

Compared to MGNH9, MGNH7 is lighter and thinner. This allows us to minimize the burden on the extruder and avoid loss of Y Stroke. Meanwhile, MGNH7 offers the same sturdiness as MGNH9. We specifically chose reputable HIWIN linear guideways, designed steel limit nuts, and a magnetic limit assembly to maximize sturdy and reliable construction. This gives the CNC Voron Tap V2 excellent Input Shaper data.

Experience higher accuracy and reliability with the OMRON EE-SX4320.
V2: Transmissive Photomicrosensor with 0.3mm Wide Aperture

5-24V

Expanding the voltage range in the upgraded V2 to support 5-24V for flexibility.

Feather Light
Weighing just 62g without screws, the incredibly lightweight bodywon't add noticeable mass to the toolhead, maintaining precesion.

Maintaining the Original XY Stroke
Preserves full range motion and build capacity,letting you unleash your Voron's capabilities.

Build for Solid, Made for Ease

*When using the CNC VORON TAP V2 with the Carbon Fiber Tube Kit for Voron2.4 X-Axis (300)\ (350), an additional printed part is required to adjust the mounting position of the X-axis limit switch bracket. You can access the following link to obtain the print file: CNC Voron Tap V2

*CNC Voron Tap V2 Compatible Carbon Fiber Kit Adapter and Old Version Hall Sensor Adapter MOD link: https://github.com/Chaoticlab/CNC-Tap-for-Voron/tree/master/STL/CNC_VORON_TAP_V2

Installation and Usage Notes
XY Stroke Influence
No XY adjustment needed - CNC VORON TAP V2 thickness similar to 2.4R2 X carriage.

MGN12H X-Axis Requirement
CNC VORON TAP V2 requires MGN12 X-Axis, not older MGN9.

CW2-Style Mounted Extruder
Replaces X-carriage and needs front screws like CW2.LGX/Galileo mounts are available.

Bed Mount Stability
500-800g nozzle force during probing. Ensure no bed motion as it reduces accuracy. Not recommended for Voron 1.8/Legacy/Switchwire.Compatibility Test: Firmly tap bed - movement means unsuitable.

Good Mechanical Condition
More precise than previous sensors. Fix known issues before installing.

Files
CNC Voron Tap V2 Build Guide

Open Source

Fits:

• Voron 2.4r2
• Voron Trident with MGN12H
